Description
Specifications:
- Phase: Single Phase
- Form Factor: Rackmount
- UPS Topology: Line-interactive
- Energy Saving Technology: GreenPower UPS Bypass Technology
- Nominal Input Voltage ( Vac ): 230
- Input Voltage Range ( Vac ): 165 - 271
- Input Frequency ( Hz ): 50 ± 3 | 60 ± 3
- Input Frequency Detection: Auto-sensing
- Rated Input Current ( A ): 10
- Input Connector Type: IEC C14
- Detachable Power Cord Plug Type: IEC C14 x 1
- Power Cord Length (m.): 1.83
- Output Capacity (Watts): 360
- On Battery Waveform: Simulated Sine Wave
- On Battery Voltage(s) ( Vac ): 230 ± 10%
- On Battery Frequency ( Hz ): 50 ± 1% | 60 ± 1%
- Power Factor: 0.6
- Automatic Voltage Regulation (AVR): Single Boost
- Overload Protection: Internal Current Limiting, Circuit Breaker
- Outlet(s) - Total: 6
- Outlet Type: IEC C13 x 6
- Outlet(s) - Battery & Surge Protected: 4
- Outlet(s) - Surge-Only Protected: 2
- Typical Transfer Time ( ms ): 4
- Runtime at Half Load ( min ): 13
- Runtime at Full Load ( min ): 4
- Typical Recharge Time ( Hours ): 8
- Start On Battery: Yes
- User-replaceable: Yes
- Hot-swappable: Yes
- Battery Type: Sealed Lead-acid
- Replacement Battery Pack: RBP0019
- RBP Quantity ( pcs ): 1
- Surge Suppression ( Joules ): 405
- EMI/RFI Filtration: Yes
- Phone/Network Protection RJ11/RJ45 (Combo): 1-in, 1-out
- LCD Information Display: Operation Type, Power Status, Battery Status, Load Status, Other Information
- LCD Setting & Control: Mode Setting, Alarm Setting, Input & Output
- HID Compliant USB Port(s): 1
- Serial Port: Dry Contact
- Audible Alarms: Battery Mode, Low Battery, Overload, UPS Fault
- Management Cable ( pcs ): Power Cord x4, USB Cable x1
- Power Management Software: PowerPanel Business (Recommended)
- SNMP/HTTP Remote Monitoring: Yes - with optional RMCARD205
- Enclosure Construction: Metal
- Rackmount Ears: Yes
- Dimensions: 433 x 44 x 235mm
- Weight: 7.8kg
- Certifications: CE, EAC, RCM
Features:
- Line-interactive UPS Topology
- Simulated Sine Wave Output
- Overload Protection
- Surge and Spike Protection
- Phone/Fax/Modem/DSL/Network Protection
- USB Connectivity Port
- SNMP/HTTP Remote Management Capability (Optional)
- Energy Saving Technology
- Automatic Voltage Regulation (AVR)
- Hot-swappable Batteries
- EMI and RFI Filtration
- LCD Status Display
- PowerPanel Management Software
