Description
Specifications:
- Nominal Input Voltage ( Vac ): 100 - 240
- Input Frequency ( Hz ): 50 / 60
- Maximum Input Current ( A ): 12 (UL) | 10 (CE)
- Input Connector Type: IEC C14 x 1
- Power Cord Length: 3.05m
- Output Voltage ( V ): Depends on Input
- Idle Power Consumption ( W ): < 5
- Outlet(s) - Total: 8
- Outlet Type: IEC C13 x 8
- Remote Individual Outlet Control: Yes
- LCD Information Display: Input Voltage (Volts), Input Frequency (Hz), Current Level (Amps), Power Consumption (Kilowatts), Network Information, Serial Number, Environment Status, Hardware Version, Firmware Version
- Hot-swappable LCD Module: Yes
- Auto LCD Orientation: Yes
- LCD Setting & Control: Outlet Control, LCD Settings, Reset / Reboot
- LED Indicators: PDU Status, Tx/Rx, Link, Outlet
- Outlet Metering Capability: ± 1%
- A-type USB Port: Yes
- Connectivity Port: RJ45, RJ45 (for Serial), RJ45 (for ENVIROSENSOR/ Daisy Chain (In)), RJ45 (for Daisy Chain (Out))
- Environmental Sensor Supported: Yes
- User-upgradeable Firmware: Yes
- Power Management Software: PowerPanel Business (Recommended for small-medium scale management), PowerPanel Enterprise (Recommended for large scale management)
- Supported Protocols: IPv4/v6, SNMPv1/v3, HTTP/HTTPs, TCP/IP, UDP, DHCP, NTP, DNS, SMTP, SSH, SSL, TLS, Telnet, FTP, and Syslog
- Authentication: RADIUS, LDAP, LDAPS, Windows AD
- Installed Rack Height (U): 1
- Form Factor: 1U Vertical Rackmount, 1U Horizontal Rackmount
- Enclosure Construction: Steel
- Cord Retention Tray: Yes
- IEC Receptacle Locking: Yes
- External Site Ground Pin: Yes
- Adjustable Mounting Brackets: 2 Set (L-short | L-long)
- Dimensions: 433 x 44 x 112mm
- Weight: 2.1kg
- Certifications: CE | FCC Class A | UL60950 | UL62368 | EN 55032 Class A
- RoHS: Yes
Features:
- Real-time Local/Remote Monitoring and Switching
- Work under High Temperature
- ±1% Measurement Accuracy
- Digital Real-time Load Display
- Hot-swappable LCD Design
- LED Status Indicator
- Supports ENVIROSENSOR
- PowerPanel Management Software
- Cord Retention Tray
- Controllable Receptacles with Power Sequencing
- Ultra Low Power Consumption
- Industrial-grade Metal Housing
- User Configurable Color LCD
- Rotatable LCD for Proper Display Orientation
- Firmware Upgrade via USB
- User-upgradeable Firmware
- Adjustable Mounting Brackets
- IEC Receptacle Locking
