Description
- Phase: Single Phase
- Dual Power Inputs: Yes
- Nominal Input Voltage ( Vac ): 200 - 240
- Input Frequency ( Hz ): 50 / 60
- Maximum Input Current ( A ): 32
- Input Connector Type: IEC 60309 32A x 2
- Power Cord Length: 3.05m
- Output Voltage ( V ): Depends on Input
- Overload Protection: Circuit Breaker
- Over Current Protection (Each Bank) ( A ): 20
- Outlets - # of Bank(s): 2
- Outlet(s) - Total: 18
- Outlet(s) - Rear: 18
- Outlet Type: IEC C19 x 2 | IEC C13 x 16
- Remote Individual Outlet Control: Yes
- LCD Information Display: Input Voltage (Volts) | Input Frequency (Hz) | Current Level (Amps) | Power Consumption (Kilowatts) | Network Information | Serial Number | Environment Status | Hardware Version | Firmware Version
- Hot-swappable LCD Module: Yes
- LCD Setting & Control: Preferred Source | Source Configuration | Load Configuration | Outlet Control | LCD Settings | Reset / Reboot
- LED Indicators: PDU Status | Source Status | Load | Tx/Rx | Link | Outlet
- A-type USB Port: Yes
- Connectivity Port: RJ45 | RJ45 (for Serial) | RJ45 (for ENVIROSENSOR/ Daisy Chain (In)) | RJ45 (for Daisy Chain (Out))
- Environmental Sensor Supported: Yes
- User-upgradeable Firmware: Yes
- Power Management Software: PowerPanel Business (Recommended for small-medium scale management) | PowerPanel Enterprise (Recommended for large scale management)
- Supported Protocols: IPv4/v6 | SNMPv1/v3 | HTTP/HTTPs | TCP/IP | UDP | DHCP | NTP | DNS | SMTP | SSH | SSL | TLS | Telnet | FTP | and Syslog
- Authentication: RADIUS | LDAP | LDAPS | Windows AD
- Installed Rack Height (U): 2
- Form Factor: 2U Horizontal Rackmount
- Enclosure Construction: Steel
- Cord Retention Tray: Yes
- IEC Receptacle Locking: Yes
- External Site Ground Pin: Yes
- Adjustable Mounting Brackets: 1 Set
- Dimensions: 433 x 88 x 215mm
- Weight: 7.8kg
- Certifications: CE | FCC Class A | UL62368 | EN 55032 Class A | IEC 62368 | RoHS
